High Accuracy Three-Phase Four-Wire Meter Test System with Modular Design for 24-Hour Variation Testing

High Accuracy Three-Phase Four-Wire Meter Test System with Modular Design for 24-Hour Variation Testing

ब्रांड नाम: GENY
मॉडल संख्या: वाईसी-1893जी
एमओक्यू: 1
कीमत: negotiate rates
भुगतान की शर्तें: टी/टी, एल/सी, डी/पी, टी/टी
आपूर्ति करने की क्षमता: 5 सेट / 1 महीने
विस्तार से जानकारी
उत्पत्ति के प्लेस:
चीन
प्रमाणन:
ISO, CE
परिवेश का तापमान:
-10 ℃ से + 40 ℃
आउटपुट वोल्टेज रेंज:
3 × 0 ~ 480V
बिजली की आपूर्ति:
तीन-चरण चार-तार 3×220V/380V±15%, 50/60Hz±2Hz
परिवेश आर्द्रता:
35% से 85% आरएच
पैकेजिंग विवरण:
प्लाईवुड केस
आपूर्ति की क्षमता:
5 सेट / 1 महीने
प्रमुखता देना:

24-Hour Variation Testing Meter Test System

,

Three-Phase Four-Wire Energy Meter Test System

,

Modular Design Stationary Meter Test System

उत्पाद का वर्णन
Advanced Meter Test System for Power & Energy Meters
General Features
  • Supports measurement of active/reactive power and energy with high accuracy
  • Automatic color marking for fast diving and start-up testing
  • Measures basic error, average error, standard deviation, and 24-hour variation
  • Can test multiple meters with same voltage/current but different constants simultaneously without circuit decoupling
  • Includes current open-circuit detection, automatic short-circuit protection, voltage fault detection, and optional temperature module
  • Automatic error data processing, storage, and online output via software
  • Flexible report generation with barcode input and database download support
  • Modular design with one-time wiring and automatic crimping for efficient operation
  • Multi-protocol RS485 server ensures smooth communication and protocol conversion
Special Functions
  • Time period switching, demand cycle, freeze function, and timing error testing
  • Meter display and combination error verification
  • Four-quadrant reactive power and error consistency testing
  • Optional dual circuit test for anti-tampering meters
  • Dynamic power, load variance, charge control, and residual power accuracy tests
  • Performance tests including overload, overvoltage, tilt impact, infrared, Bluetooth, and carrier wave
  • Advanced harmonic analysis meeting IR46 standards for sharp/flat top waves and various harmonics calibration
